12.2.5.

Analog output interface (46 series XS8)

Analog output interface wiring diagram:
The wiring is also suitable for XS8 interface of 46 series controller;
Internally provided +5V power
5V+
IN56 Select X axis
IN57 Select Y axis
IN58 Select Z axis
IN59 Select A axis
IN62 Emergency stop
HB Hand encoder phase B input signal
Internally provided -5V power
5V-
