Adtech ADTECH4 CNC Series Maintenance Manual page 179

49 series (XS9)
CNC4960 definition follows:
Wire No.
1
2
3
4
5
6
7
8
9
10
Definition Function
IN63 0.1 gear switch – high
IN64 0.01 gear switch – medium
IN65 0.001 gear switch – low
IN60 Select C axis
IN61 Emergency stop
HA Hand encoder phase A input signal
Internally provided -24V power
24V-
Internally provided +5V power
5V+
IN56 Select X axis
IN57 Select Y axis
ADTECH4 SeriesCNC Maintenance Manual
power supply
supply
supply
