Adtech ADTECH4 CNC Series Maintenance Manual page 180

11
12
13
14
15
49 series (XS9)
CNC4940 definition follows:
Wire No.
1
2
3
4
5
6
7
IN58 Select Z axis
IN59 Select A axis
IN62 Select B axis
HB Hand encoder phase B input signal
Internally provided -5V power
5V-
Definition Function
IN63 0.1 gear switch – high
IN64 0.01 gear switch - medium
IN65 0.001 gear switch - low
IN60 Start
IN61 Stop
HA Hand encoder phase A input signal
Internally provided -24V power
24V-
ADTECH4 SeriesCNC Maintenance Manual
supply
supply
