4.11 Setting the Sensing Interval

If the line segments are fine, registration marks may not be detected even when the slowest registration
mark detection speed has been set. If the interval has been set to 0, the registration marks are detected
through sampling during movement. If the interval is set to 5, 10 or 15μ, registration marks are sensed at the
specified interval. (FC4510-60 only)
The sensing interval setting is only enabled for registration mark pattern 3.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
MARK
BUFFER CLR.
SPEED
(3) Press the [F1] key (MARK) to display the registration mark functions selection menu.
FORCE
MODE
TYPE OTHER SETUPS
SPEED
(4) Press the [F4] key (OTHER SETUPS) to display the menu shown below.
FORCE
SIZE
ORG OFT
SPEED
(5) Press the [F4] key (SENS OPT) to display the menu shown below.
FORCE
FREQUENCY
SENS SPD SENS STEP
SPEED
(6) Press the [F4] key (SENS STEP) to display the menu shown below.
FORCE
TYPE 3 SENSING INTVL
NO. OF STEPS= 5 um
SPEED
Use the [ ] or [
the displayed setting is satisfactory, press the
Setting range: 0, 5, 10, 15 (μm) [Default value: 0]
Setting a lower value enables sensing to be performed more easily. If 0 has been selected, registration mark sensing
is performed continuously.
(7) Press the [PAUSE] key to cancel PAUSE mode.
OFFSET
TOOL U/D
QUALITY
OFFSET
DIST ADJ
QUALITY
OFFSET
ADJ. SENS
SENS OPT
QUALITY
OFFSET
QUALITY
OFFSET
QUALITY
] key to move the blinking cursor, and the[
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
] or [ ] key to change the numeric value. When
[ENTER] key to confirm your selection.
