5.22 Setting the Tool-up Height

Lowering the tool-up height setting value enables a reduction in the cutting time. When making this setting,
make sure that the tool does not catch in the medium when the tool carriage is being moved.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
OPTION1
SPEED
(3) Press the [F4] key (OPTION2) to display the menu shown below.
FORCE
UP HEIGHT
MOVE SPD
SPEED
(4) Press the [F1] key (UP HEIGHT) to display the screen for setting the tool-up height.
FORCE
TOOL UP HEIGHT
SPEED
Use the [ ] or [
selection.
Setting range: 0.0 to -3.0 [Default value: 0.0]
(5) Press the [PAUSE] key to cancel PAUSE mode.
This setting is retained in the plotter's internal memory even while the plotter is turned off.
OFFSET
OPTION2
QUALITY
OFFSET
POS.OPT
TEST
QUALITY
OFFSET
H = 0.0 mm
QUALITY
] key to change the numeric value, and then press the
Chapter 5 FUNCTION SETTINGS AND OPERATIONS
[ENTER] key to confirm your
5-25
