Manual Detection - GRAPHTEC FC4500 User Manual

(4) Press the [F1], [F2] or [F3] key to select the corresponding number for the Mark Move No. setting. The following
prompt is displayed while the plotter detects the adjustment points.
FORCE
ARMS IS OPERATING
WAIT....
SPEED
(5) When the points have been read, the following menu for distance adjustment between points 1 and 2 is displayed.
FORCE
1-2M 00260. 0 mm
S 00260. 0 mm
SPEED
The display's first line (M) shows the distance between the first and second points as read by the plotter. Input the
actual distance (the data distance) in the second line (S). Use the [
then press the [ENTER] key.
If CUSTOM or STANDARD has been selected on the Registration Mark Distance Adjustment menu, the value is
adjusted automatically and the menu for inputting the adjustment value is not displayed.
If the value you input is exceedingly large (1.5 times or greater) or very small (0.5 times or less), or if the angle of tilt
with respect to the original axis tilt is 45° or greater, the following prompt is displayed. In this case, please re-input
the value.
FORCE
DISTANCE ADJUSTMENT
ERROR. SET AGAIN!
SPEED
(6) If 3-point or 4-point adjustment has been selected, the menu for adjusting the distance between points 1 and 3 will
be displayed. Make the settings in the same way as for the distance between points 1 and 2.
(7) When all the adjustments have been completed, the plotter returns to Ready status.

Manual Detection

(1) Select MARKS as the registration mark mode. (See Section 4.2, "Setting the Registration Mark Mode".)
(2) With the plotter in Ready status, press the
FORCE
1
2
SPEED
(3) Press the [F4] key (MANUAL) to display the menu shown below.
FORCE
DISTANCE ADJUSTMENT
ERROR. SET AGAIN!
SPEED
OFFSET
QUALITY
OFFSET
QUALITY
OFFSET
QUALITY
[ORIGIN] key to display the menu shown below.
OFFSET
3
MANUAL
QUALITY
OFFSET
QUALITY
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
] or [ ] key to change the numeric value, and
4-27
