Perforation Settings - GRAPHTEC FC4500 User Manual

(3) Press the [ENTER] key to display the Thick Mode mode selection screen (only when thick mode assignment
has been performed).
FORCE
•MODE1 THICK MODE2
STR.=0.0mm END=0.0mm
SPEED
(4) The active mode is indicated by the [
Mode 2 and select the desired mode.
Mode 1: Perform overcutting for the cutting start and end points and for corners with acute angles to prevent uncut
areas. Since the blade tip is raised up to the surface of the medium when blade rotation is large, it is not
affected by thick or hard media. Compared with Mode 2, this mode supports finer cutting and cutting of
thicker media.
Mode 2 : Perform overcutting for the cutting start and end points only. Compared with Mode 1, this mode supports
faster cutting, since less cutter blade control is required.
(5) Use the [F2] key to move the blinking cursor to the Start point parameter and the [F4] key to move it to the End
point parameter. Use the [
Setting range: 0 to 3.0 mm
(6) When the displayed settings are correct, press the
setting the perforation length. To cancel your settings, press the

Perforation Settings

This setting determines the cut and uncut lengths of a perforated line. This setting is only enabled for the COND Nos. to
which the perforation mode has been assigned.
•
The perforation settings are disabled when "PEN", "CP001" has been selected as the cutter blade type.
•
Please see Section 5.10, "Assigning Perforation Cutting" for further details.
(1) When perforation cutting has been specified, "M" is displayed next to the Tool No. when the plotter is in Ready status.
FORCE
20,20 COND1
30 READY+ TOOL1M
SPEED
(2) Press the [CONDITIONS] key to display the following screen. (The display will differ according to the setting
conditions that have been made.)
FORCE
X23 COND1
30 CHANGE TOOL1
SPEED
(3) Press the [ENTER] key to display the Thick Mode mode selection screen (only when Thick Mode assignment
has been performed).
FORCE
•MODE1 THICK MODE2
STR.=0.0mm END=0.0mm
SPEED
OFFSET
QUALITY
•
] mark. Press the [F1] and [F3] key to move the [
] or [ ] key to change the value.
OFFSET
09U 0
4
QUALITY
OFFSET
09U 0
4
QUALITY
OFFSET
QUALITY
Chapter 3 PREPARATIONS FOR CUTTING/PLOTTING
[ENTER] key. The display will change to the screen for
[NEXT] key.
•
] mark between Mode 1 and
3-19
