Chapter 5 FUNCTION SETTINGS AND OPERATIONS

5.3 Raising/Lowering the Tool

This function allows you to raise or lower the tool from the control panel.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
MARK
BUFFER CLR.
SPEED
(3) Press the [F3] key (TOOL U/D) to raise or lower the tool. Each time the [F3] key is pressed, the tool is alternately
raised and lowered.
(4) Press the [PAUSE] key to cancel PAUSE mode.
While using this function, keep your hands out of the vicinity of the tool carriage.
5-4
OFFSET
TOOL U/D
QUALITY
