Setting the High Movement Speed

This setting determines the high speed setting when one of the [
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
OPTION1
SPEED
(3) Press the [F4] key (OPTION2) to display the menu shown below.
FORCE
UP HEIGHT
MOVE SPD
SPEED
(4) Press the [F3] key (POS. OPT) to display the menu shown below.
FORCE
STEP
LOW SPEED
SPEED
(5) Press the [F3] key (HI SPEED) to display the high-speed setting screen.
FORCE
HI SPEED
SPEED
Use the [ ] or [ ] key to change the numeric value and then press the
selections. To cancel your selections, press the
Setting range: 1 to 30 (cm/s) [Default value: 20]
(6) Press the [PAUSE] key to cancel PAUSE mode.
This setting is retained in the plotter's internal memory even while the plotter is turned off.
