Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION

4.9 Setting the Registration Mark Detection Speed

This function sets the speed of the tool carriage at the time when registration mark lines are detected.
Change the speed setting if registration marks cannot be detected due to the type of media used or the
thickness of the registration mark lines.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
MARK
BUFFER CLR.
SPEED
(3) Press the [F1] key (MARK) to display the registration mark functions selection menu.
FORCE
MODE
TYPE
SPEED
(4) Press the [F4] key (OTHER SETUPS) to display the menu shown below.
FORCE
SIZE
ORG OFT
SPEED
(5) Press the [F4] key (SENS OPT) to display the menu shown below.
FORCE
FREQUENCY
SENS SPD SENS STEP
SPEED
(6) Press the [F2] key (SENS SPD) to display the menu shown below.
FORCE
SENSING SPEED
SPEED =
SPEED
Use the[ ] or [
selection.
Setting range: 1 to 20 (cm/s) [Default value: 5]
Setting a slower speed (a smaller value) enables registration marks to be detected more easily.
(7) Press the [PAUSE] key to cancel PAUSE mode.
Fine registration mark lines may not be detected if the detection speed is increased.
4-20
OFFSET
TOOL U/D
QUALITY
OFFSET
DIST ADJ
OTHER SETUPS
QUALITY
OFFSET
ADJ. SENS
SENS OPT
QUALITY
OFFSET
QUALITY
OFFSET
5 cm/s
QUALITY
] key to change the numeric value, and then press the [ENTER] key to confirm your
