4.10 Setting the Number of Detection Operations

This function sets the number of registration mark detection operations. If "SIMPLE" or "HI-SPEED" is
selected, detection is performed at one location. If "NORMAL" is selected, detection is performed at three
locations.
•
If a detection error occurs when "SIMPLE" or "HI-SPEED" has been selected, change your selection to "NORMAL".
•
The "HI-SPEED" setting is only enabled for registration mark patterns 1 and 2. If the registration mark pattern is 3 or
MIRROR, the "SIMPLE" setting takes effect.
•
Faint or fine lines may not be detected when "HI-SPEED" has been selected. Moreover, the precision may be lower
than that provided by the "NORMAL" setting. In such cases, change your selection to "NORMAL".
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
MARK
BUFFER CLR.
SPEED
(3) Press the [F1] key (MARK) to display the registration mark functions selection menu.
FORCE
MODE
TYPE OTHER SETUPS
SPEED
(4) Press the [F4] key (OTHER SETUPS) to display the menu shown below.
FORCE
SIZE
ORG OFT
SPEED
(5) Press the [F4] key (SENS OPT) to display the menu shown below.
FORCE
FREQUENCY
SENS SPD SENS STEP
SPEED
(6) Press the [F1] key (FREQUENCY) to display the menu shown below.
FORCE
SIMPLE
SPEED
To select the simple detection operation, press the [F2] key (SIMPLE) and then press the
To select the high-speed detection operation, press the [F3] key (HI SPEED) and then press the
To select the normal detection operation, press the [F4] key (NORMAL) and then press the
If SIMPLE or HI SPEED was selected, line
OFFSET
TOOL U/D
QUALITY
OFFSET
DIST ADJ
QUALITY
OFFSET
ADJ. SENS
SENS OPT
QUALITY
OFFSET
QUALITY
OFFSET
HI SPEED
NORMAL•
QUALITY
SIMPLE, HI SPEED
1
may be detected in error.
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
NORMAL
2
1
3
[ENTER] key.
[ENTER] key.
[ENTER] key.
4-21
