(10) FC4500-50/60: Press the [F2] key (ADJ.) to adjust the sensors.
FC4510-60: Press the [F1] key (X) to adjust the X-axis sensor, and the [F3] key (Y) to adjust the Y-axis sensor.
FORCE
MOVE TO ADJ. POINT
PRESS ENTER KEY!
SPEED
(11) Use the [ ] [ ] [
area under the cross symbol indicated in the diagram below) and then press the [ENTER] key. The sensor will read
the cross symbol.
Y
X
(12) After the sensor reads the cross symbol, a cross symbol for use in adjustment is plotted using the pen in tool holder
1 and then the menu below is displayed.
FORCE
SENSOR OFFSET ADJUST
X= 0.0 mm
SPEED
Input the distance that you wish to move the second cross with respect to the first cross. If the second cross does
not need to be moved, simply press the
Press the [F2] or [F4] key to move the blinking cursor to X or Y, and then use the [
numeric value. When the displayed setting is satisfactory, press the
Setting range: -9.9 to +9.9 (mm)
Y
Value for Y-axis correction
X
(13) Press the [PAUSE] key to cancel PAUSE mode.

Adjusting the Registration Mark Sensor by Using One Plotted and One Cut Cross Symbol

The plotter plots a cross symbol, reads it, and then uses the cutter pen to cut a second cross symbol. The sensor's
precision is adjusted by inputting the difference in the values of these two cross symbols.
Perform this adjustment after the registration mark detection level and registration mark detection speed settings
have been made.
(1) Load a medium for the sensor adjustment procedure.
(2) Press the [PAUSE] key to select PAUSE mode.
(3) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
MARK
BUFFER CLR.
SPEED
OFFSET
QUALITY
] [ ] keys to move the tool carriage (the tip of the tool selected by the current setting) to the
Move the pen carriage (the tip of the tool selected
by the current setting) within this area.
OFFSET
Y= 0.0 mm
QUALITY
[ENTER] key.
Value for X-axis correction
Cross plotted after the first cross was read
OFFSET
TOOL U/D
QUALITY
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
] or [
[ENTER] key to confirm your selection.
] key to change the
4-13
