(9) This setting determines by what margin each end of the creasing line falls short of the corresponding end of the actual
data line. Use the [
the [ENTER] key to confirm your selections.
Setting range: 0 to 9.99 (mm)
Actual data
(10) When the displayed settings are correct, press the
key.
For short-line data such as circle command data, setting a large value for the STR (Start) parameter may result in
creasing not being performed.

Short line segment settings

The overall cutting time can be reduced while still maintaining cutting quality by giving priority to quality when setting the
conditions for cutting short line segments such as those used in arcs and priority to speed when setting the conditions
for cutting long line segments such as straight lines. This section describes how to make the settings for short line
segments. Please refer to Section 3.7, "Setting the Condition Conditions" for details on how to make the speed and
quality settings for long line segments.
See Section 5.8, "Assigning the Short Line Segment Settings" for details on how to assign the short line segment
settings to COND Nos.
This setting is only enabled for the COND Nos. to which the short line segment settings have been assigned.
Please see Section 5.8, "Assigning the Short Line Segment Settings" for further details.
(1) Press the [CONDITIONS] key for a Cond. No. to which the short line segment settings have been assigned. The
following screen is displayed. (The display will differ according to the setting conditions that have been made.)
FORCE
MODE1
SPC -.--mm STR0.00mm
SPEED
(2) Press the [ENTER] key to display the screen for setting the short line segment values (only when the short line
segment settings have been assigned.)
FORCE
SHORT L. OP. L= 0.0
SPD= 0
SPEED
(3) The speed and acceleration conditions can be established for those line segments that are below the specified
line segment "L (mm)" parameter value. "SPD" represents the upper limit of the cutting speed value, and "ACL"
represents the upper limit of the cutting quality value. Use the [
parameter that you wish to change, and the [
[L] setting range: 0.1 to 9.9
(4) When the displayed settings are correct, press the
setting the conditions. To cancel your settings, press the
] or [ ] key to move the blinking cursor, the [
Results of the creasing
operation
OFFSET
COUNT1
QUALITY
OFFSET
ACL=36
QUALITY
[SPD] setting range: 1 to 75
] or [
Specified
value
[ENTER] key. To cancel your settings, press the
] or [
] or [ ] key to change the value.
[ACL] setting range: 1 to 10
[ENTER] key. The display will change to the screen for
[NEXT] key.
Chapter 3 PREPARATIONS FOR CUTTING/PLOTTING
] key to change the numeric value and
] key to move the blinking cursor to the
[NEXT]
3-17
