Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
4.12 Axis Adjustment
When AXIS has been selected for the registration mark mode, axis adjustment is performed manually. If 2, 3,
or 4 points are specified on the X and Y axes, adjustment is performed for the angle of the coordinate axes
(X-axis and Y-axis tilt) and the distance (line segment length).
Plotter's effective
plotting area
Edges of
the medium
Pre-printed frame
on the medium
Y
X
Axis adjustment origin point: This is the center point of axial eccentricity. The X and Y axes are tilted from this point.
Point 1: This the reference point used for axis adjustment. For 3-point and 4-point reading, position this point at the
intersection of the X and Y axes of points 2 and 3.
Point 2: Using point 1 as a reference, position this point on the X or Y axis.
Point 3: Using point 1 as a reference, position this point on the X or Y axis.
Point 4: Position this point diagonally opposite point 1, at the intersection of the X and Y axes of points 2 and 3.
(1) Select AXIS as the registration mark mode, and then select the number of points for reading. (See Section 4.2,
"Setting the Registration Mark Mode".)
(2) With the plotter in Ready status, press the
FORCE
AXIS POINT 1
X=
SPEED
Use the [
] [
to the position for setting point 1, and then press the
previously, the tool carriage will move automatically to the previously set reference point. In this case, use the [
[
] [
] keys to make any adjustments required.
(3) The prompts for setting point 2, point 3 and point 4 will be displayed in succession. Make the settings in the same
way as for point 1.
FORCE
AXIS POINT 2
X=
SPEED
(4) When all the points have been set, the following menu for distance adjustment between points 1 and 2 is displayed.
FORCE
1-2M
S
SPEED
The display's first line (M) shows the distance between the first and second points as read by the plotter. Input the
actual distance (the data distance) in the second line (S). Use the [
then press the
4-24
•
2-point reading
Point 2
Point 1
Axis adjustment origin point
OFFSET
0
Y=
0
QUALITY
] [
] [
] keys to move the tool carriage (the tip of the tool or pen selected by the current setting)
OFFSET
0
Y=
0
QUALITY
OFFSET
00499.8 mm
00500.0 mm
QUALITY
[ENTER] key. The plotter returns to Ready status.
•
3-point reading
Point 3
Point 2
Point 1
Axis adjustment origin point
[ORIGIN] key to display the menu shown below.
[ENTER] key. If 2-axis adjustment has been performed
] or [
•
4-point reading
Point 3
Point 1
Axis adjustment origin point
] key to change the numeric value, and
Point 4
Point 2
] [
]
