(2) Press the [CONDITIONS] key to display the following screen. (The display will differ according to the setting
conditions that have been made.)
FORCE
X23 COND1
30 CHANGE TOOL1
SPEED
(3) Press the [F3] key to move the blinking cursor to the OFFSET parameter.
FORCE
X20 COND1
30 CHANGE TOOL1
SPEED
(4) Use the [ ] or [ ] key to cycle through the setting parameters. Select the desired cutter blade or tool.
Parameters that can be selected: 09U, 15U, 15UK30, 15UK20, 15UB, OTHER, CP001 (pen-type creaser), PEN
Select "OTHER" when you plan to use a cutter blade other than those registered or when a cutting operation using
a thick or otherwise difficult-to-cut medium produces unsatisfactory results. Select "PEN" when you plan to use a
plotting pen.
If you select "CP001" and then press the
Mode has been enabled, the Thick Mode Settings screen will be displayed.
(5) When a blade name (09U, 15U) or "Other" has been selected, fine adjustment of the offset can be performed. Use
the [ ] or [ ] key to adjust the offset value.
Setting range: Blade name: -5 to +5; Other: 1-99
(6) When the displayed settings are correct, press the
key.

Creaser Settings

The creaser settings enable you to specify the creasing mode, the spacing between creases, the number of creasing
operations and the creasing start and end points.
Only straight lines can be creased. Curved-line data cannot be creased.
(1) The following Creaser Settings screen is displayed when "CP001" was selected as the cutter blade type and the
[ENTER] key pressed.
FORCE
MODE1
SPC -.--mm STR0.00mm
SPEED
Setting the Creasing Mode
(2) Press the [F2] key to move the blinking cursor to the position shown in the following screen.
FORCE
MODE1
SPC -.--mm STR0.00mm
SPEED
(3) The number displayed next to "MODE" is the number of the mode that is currently selected. Use the [
key to select your desired mode.
OFFSET
09U 0
4
QUALITY
OFFSET
09U 0
4
QUALITY
[ENTER] key, the Creaser Settings screen will be displayed. If Thick
OFFSET
COUNT1
QUALITY
OFFSET
COUNT1
QUALITY
Chapter 3 PREPARATIONS FOR CUTTING/PLOTTING
[ENTER] key. To cancel your settings, press the [NEXT]
] or [ ]
3-15
