Chapter 5 FUNCTION SETTINGS AND OPERATIONS

5.25 Printing a Conditions List

This function allows you to print a list of the current cutting/plotting settings (conditions).
The tool carriage starts moving as soon as this function has been selected. To avoid injury to yourself or damage to
the plotter, keep your hands and other obstacles out of the vicinity of any moving parts.
(1) If you want to print out the list of cutting/plotting conditions of one sheet of paper, load a sheet of paper that is A3
size or larger in the plotter.
If you want to print out the list on two sheets of paper, load an A4-size sheet of paper in the plotter.
(2) Mount a plotting pen.
(3) Press the [PAUSE] key to select PAUSE mode.
(4) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
OPTION1
SPEED
(5) Press the [F4] key (OPTION2) to display the following menu.
FORCE
UP HEIGHT
MOVE SPD
SPEED
(6) Press the [F4] key (TEST) to display the following menu.
FORCE
COND. PAT.
SPEED
(7) Use the [ ] [
position where you want to print the list. Next, press the [F2] key (COND. PAT.). The following message appears on
the LCD and the plotter begins printing "Condition Settings Page 1".
FORCE
PRINT CONDITIONS
SPEED
(8) When this page has been printed, the following message appears on the LCD.
FORCE
LOAD PAPER !!
PRESS ENTER KEY
SPEED
Replace the medium if required or use the [
selected by the current setting) to the position where you want to print the second list.
Press the [ENTER] key to print "Condition Settings Page 2"
(9) When all of the conditions have been printed, the READY message reappears.
5-30
OFFSET
OPTION2
QUALITY
OFFSET
POS.OPT
TEST
QUALITY
OFFSET
SELF TEST
DUMP
QUALITY
] [ ] [ ] keys to move the tool carriage (the tip of the tool selected by the current setting) to the
OFFSET
QUALITY
OFFSET
QUALITY
] [ ] [ ] [ ] keys to move the tool carriage (the tip of the tool
