4.15 Setting the Registration Mark Detection Start Position

This function sets the start position for registration mark detection.
(1) Select either AXIS or MARKS for the registration mark mode (see Section 4.2, "Setting the Registration Mark Mode".
(2) With the plotter in Ready status, press the
FORCE
1
2
SPEED
(3) Press the [NEXT] key to display the following menu.
FORCE
MIRROR MARKS
START POS LEV. ADJ
SPEED
(4) Press the [F2] key (START POS) to display the menu for setting the start position for the reading of registration
marks.
FORCE
•SAVE POS
CURRENT POS
SPEED
The currently selected setting is indicated by a black dot [
To save the current position and use it as the start position for the next registration mark detection operation, press
the [F1] key (SAVE POS).
To start registration mark detection from the current tool carriage position, press the [F2] key (CURRENT POS).
To start registration mark detection from the origin point, press the [F3] key (ORG POS).
If the [F4] key (AUTO) is pressed, the sensor performs detection while moving in a diagonal direction if the first
registration mark (the registration mark at the lower left position) is not detected from the current start position.
When the displayed setting is satisfactory, press the
[ORIGIN] key to display the following menu.
OFFSET
3
MANUAL
QUALITY
OFFSET
QUALITY
OFFSET
ORG POS
AUTO•
QUALITY
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
•
].
[ENTER] key to confirm your selection.
4-31
