Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
Setting range: [X/Y] 0 to 999.9 (mm), [W] -99.9 to +99.9 (mm)
Vertical line
X
a
b
a
Y W
W
b
Horizontal line
Set W in the range in which there are no vertical or horizontal lines.
(3) Press the [PAUSE] key to cancel PAUSE mode.
