Chapter 5 FUNCTION SETTINGS AND OPERATIONS

Setting the Low Movement Speed

This setting determines the slower speed when one of the [
(distance) before faster movement begins.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
OPTION1
SPEED
(3) Press the [F4] key (OPTION2) to display the menu shown below.
FORCE
UP HEIGHT
MOVE SPD
SPEED
(4) Press the [F3] key (POS. OPT) to display the menu shown below.
FORCE
STEP
LOW SPEED
SPEED
(5) Press the [F2] key (LOW SPEED) to display the low-speed setting screen.
FORCE
LOW SPEED
LENG
SPEED
Press the [F3] key (LOW SPEED) to specify the speed for low-speed movement. Press the [F4] key (LENG) to
specify the length (distance) moved before the low-speed movement changes to high-speed movement begins.
Use the [ ] or [
selections. To cancel your selections, press the
Setting range: [LOW SPEED] 1 to 30 (cm/s) [Default value: 2]
If 0 was selected for the LENG parameter, the pen carriage starts moving at the high speed. If the
held down, however, the pen carriage moves at the low speed.
If MAX was selected for the LENG parameter, the pen carriage moves at the low speed without switching to the high
speed. If the
high speed.
(Default values: LOW-SPEED: 2 cm/s; LENG: 2 cm)
(6) Press the [PAUSE] key to cancel PAUSE mode.
This setting is retained in the plotter's internal memory even while the plotter is turned off.
5-28
OFFSET
OPTION2
QUALITY
OFFSET
POS.OPT
TEST
QUALITY
OFFSET
HI SPEED
LCD•
QUALITY
OFFSET
2 cm/s
5 cm
QUALITY
] key to change the numeric value and then press the
[LENG] 0 to 30 (cm/s), MAX [Default value: 10]
[NEXT] key is pressed during pen carriage movement, however, the pen carriage switches to the
] [ ] [ ] [ ] keys is initially pressed, and the length
[NEXT] key.
[ENTER] key to confirm your
[NEXT] key is
