Radar Type Application Overview
ADRV9001 transceiver with minimum number of external components can be utilized to build complete RF-to-bits signal chain that can
serve as RF front end building block in Radar type applications. ADRV9001 internal AGC can be utilized to autonomously monitor and
set appropriate gain level for Rx signal chains. Internal AGC can utilize analog GPIO interface to control external DSA in the Rx signal
chains. For time critical TDD type applications control of the ADRV9001 TRx can be done by toggling control lines. ADRV9001 can
control external Rx/Tx switch using its analog GPIOs as well as provide power amplifier bias voltage by utilizing AuxDAC outputs. Multi
Chip Sync signal together with DEV_CLK can be utilized to synchronize multiple ADRV9001 in end system.
Table 10. Constrains and Limitations in Radar Type Application
Functionality Constrains and Limitations
Rx Signal Path User has to ensure that appropriate level of isolation between Rx1 and Rx2 as well as Rx to Tx is provided at system
level. In example above, RxB input is utilized during Tx observation. The LNA connected to the Rx1A should be
powered down during Tx slots to ensure proper operation of the Tx observation path (connected to the Rx1B). User
should ensure that appropriate attenuation is present in line to prevent Rx input being overloaded by Tx signal.
LO Generation In Radar type application, ADRV9001 can use its internal LO to generate RF LO1 for both uplink and downlink. For
applications with stringent RF LO requirements, user can use external LO inputs. External LO1 operating at 2x RF LO
can be used for both uplink and downlink.
For LO generation, ADRV9001 utilize internal VCO that generates square wave type signal. A square wave LO would
RF Front End
produce harmonics. For example: depending of RF matching used on the RF ports user 2nd LO harmonic can be as
high as -50dBc and 3rd harmonic can be as high as -9 dBc. Therefore the RF filtering on the Rx and Tx path must
ensure that signals at the LO harmonic frequencies (up to 9th in some cases) are not affecting overall system
performance.
DPD The DPD functionality can be utilized in the 2R2T TDD mode. Maximum channel bandwidth that DPD can support is
limited by ADRV9001 RF bandwidth divided by 3 or by 5. The DPD operation can be performed by ADRV9001 or ORx
data can be sent to baseband processor via Rx data port during Tx operation. Rx path used during DPD operation to
perform Tx observation is also used by the Tx tracking calibrations. In case of external DPD, user has to ensure that
access to the Rx path during Tx slots is time-shared between DPD operation and Tx calibrations.
Calibrations During Rx initialization sequence user needs to ensure that there are no signals present at the Rx input (external LNA
should be disabled) and appropriate termination should be present at LNA output to avoid reflections of Rx
calibration tones. Maximum input signal amplitude should not exceed -82 dBm/MHz for wideband modes, TBD
dBm/MHz for narrowband modes. During Tx initialization sequence user needs to ensure that Power Amplifier is
power down to avoid unwanted emission of Tx calibration tones at the antenna.
ADRV9001 needs to access Rx datapath during Tx time slots for Tx tracking calibration to operate. If user use DPD in
its system then access to Rx datapath during Tx slots need to be time-shared between DPD operation and Tx
calibrations.
AGPIOs Analog GPIOs (operating at 1.8V level) can be used as read or write digital levels of in the end user system. AGPIOs can
be utilized to control states of external components (e.g. RF Switch) or read back digital logic levels from external
components.
DGPIOs Digital GPIOs can be used to perform real time monitoring of states of internal ADRV9001 blocks. Digital GPIOs
operating as inputs can allow user to control Rx gain, Tx attenuation, AGC operation and other elements of ADRV9001
TRx. Depending on the ADRV9001 operation up to 4 GPIOs may be utilized by data port interface.
AuxADC AuxADC can be used to monitor analog voltage (e.g. temperature sensor). Maximum AuxADC input voltage can not
exceed 0.9V.
AuxDAC AuxDAC can be used to: control VCXO responsible for generating Device clock, generate pre-configured ramp
up/down signal that can be used to control power amplifier bias, control any circuitry that requires analog control
voltage up to 1.8V.
DEV_CLK_OUT ADRV9001 provides divided down version of DEV_CLK reference clock input signal on the DEV_CLK_OUT output. This
output is intended to provide reference clock signal to the digital components in the overall system. This output can
be configured to be active after power up and before ADRV9001 configuration stage.
ADRV9001 allows the user to synchronize multiple transceivers used in single system. ADRV9001 provides the
Multichip Sync
capability to accept an external reference clock and synchronize operation with other devices using simple control
logic. Logical pulses applied at MCS input align each device's data clock with a common reference. Relationship of
MCS pulse to the DEV_CLK edge at the ADRV9001 pins needs to be preserved. For correct operation, it is critical to
match length of PCB traces that carry DEV_CLK and MCS signals to each ADRV9001 device.
