UG-1828
The APD and HB detector both have a high threshold and a low threshold, apdHighTresh, apdLowThresh, hbHighTresh and
hbUnderRangeHighThresh, respectively. These levels are user programmable, as well as the number of times a threshold needs to be
exceeded for an over range condition to be flagged.
The high thresholds are used as limits on the incoming signal level and will principally be set based on the maximum input of the ADC.
When an over range condition occurs, the AGC will reduce the gain (gain attack). The low thresholds are used as lower limits on signal
level. When an under range condition occurs, the AGC will increase the gain (gain recovery). The AGC stable state (where it will not
adjust gain) occurs when neither an under range nor over range condition is occurring.
Each overrange/underrange condition has its own attack and recovery gain step as shown in Table 51.
Table 51. Peak Detector Gain Steps
Over Range/Under Range
apdHighThresh over range
apdLowThresh under range
hbHighThresh over range
hbUnderRangeHighThresh under range
An overrange condition occurs when the high thresholds have been exceeded a configurable number of times within a configurable
period. An underrange condition occurs when the low thresholds have not been exceeded a configurable number of times within the
same configurable period. These counters make the AGC less sensitive to occasional peaks in the input signal, ensuring that a single peak
exceeding a threshold does not necessarily cause the AGC to react. Table 52 outlines the counter parameters for the individual
overload/under range conditions.
Table 52. Peak Detector Counter Values
Over Range/Under Range
apdHighTresh over range
apdLowThresh under range
hbHighThresh over range
hbUnderRangeHighThresh under range
The AGC uses a gain update counter to time gain changes, with gain changes made when the counter expires. The counter value, and
therefore the time spacing between possible gain changes, is user programmable through the agcGainUpdateCounter parameter. The
user specifies the period, in AGC clock cycles, that gain changes can be made. Typically, this might be set to frame or sub-frame
boundary periods.
Once the gain update counter expires all the peak threshold counters are reset. The gain update period is therefore a decision period. The
overload thresholds and counters are therefore set based on the number of overloads considered acceptable for the application within the
gain update period.
Figure 107 shows an example of the AGC response to a signal versus the APD or HB peak detector threshold levels. APD and HB
detector works in the same fashion in this mode. For ease of explanation, only APD is mentioned in the following discussions. The green
line is representative of the peaks of the signal. Initially the peaks of the signal are within the apdHighThresh and apdLowThresh. No
gain changes are made. An interferer suddenly appears whose peaks now exceed apdHighThresh. On the next expiry of the gain update
counter (assuming a sufficient number of peaks occurred to exceed the counter), the AGC decrements the gain index (reduces the gain)
by apdGainStepAttack. This isn't sufficient to get the signal peaks within the threshold levels, and hence the gain is decremented once
more, with the peaks now between the two thresholds. The gain is stable in this current gain level until the interferer is removed, and the
peaks of the desired signal are now below the apdLowThresh which results in an under range condition. Hence the AGC increases gain
by the apdGainStepRecovery at the next expiry of the gain update counter, continuing to do so until the peaks of the signal are within the
two thresholds once more.
Gain Step
Reduce gain by apdGainStepAttack
Increase gain by apdGainStepRecovery
Reduce gain by hbGainStepAttack
Increase gain by hbGainStepHighRecovery
Counter
apdUpperThreshPeakExceededCnt
apdLowerThreshPeakExceededCnt
hbUpperThreshPeakExceededCnt
hbUnderRangeHighThreshExceededCnt
