Analog Devices ADRV9001 User Manual page 186

UG-1828
m6
FREQUENCY = 6.000GHz
S(1,1) = 0.306/109.200
IMPEDANCE = 35.022 + j22.294
m5
FREQUENCY = 4.500GHz
S(2,2) = 0.249/143.402
IMPEDANCE = 32.079 + j10.157
m4
FREQUENCY = 3.000GHz
S(2,2) = 0.166/–177.256
IMPEDANCE = 35.757 – j0.0585
m6
FREQUENCY = 6.000GHz
S(3,3) = 0.187/128.165
IMPEDANCE = 76.218 + j23.228
m5
FREQUENCY = 4.500GHz
S(3,3) = 0.172/–167.199
IMPEDANCE = 71.122 – j5.579
m4
FREQUENCY = 3.000GHz
S(3,3) = 0.136/–156.169
IMPEDANCE = 77.425 – j8.680
0.5
0.2
M6
M5
M4
0
M3 M2
–0.2
–0.5
FREQUENCY (30.00Hz TO 6.000GHz)
Figure 158. ADRV9001 TX port Series Equivalent Differential Impedance
0.5
0.2
M6
M5
0
M4
M3
–0.2
–0.5
FREQUENCY (30.000MHz TO 6.000GHz)
Figure 159. ADRV9001 RX A Port Series Equivalent Differential Impedance
Rev. PrA | Page 186 of 253
Preliminary Technical Data
1.0
2.0
5.0
M1
–5.0
–2.0
–1.0
2.0
5.0
M1
M2
–5.0
–2.0
–1.0
m1
FREQUENCY = 30.00MHz
S(2,2) = 0.036/174.443
IMPEDANCE = 46.518 + j0.327
m2
FREQUENCY = 1.000GHz
S(2,2) = 0.064/–152.286
IMPEDANCE = 44.598 + j2.647
m3
FREQUENCY = 2.000GHz
S(2,2) = 0.392/109.862
IMPEDANCE = 40.221 – j2.724
m1
FREQUENCY = 30.00MHz
S(3,3) = 0.034/25.570
IMPEDANCE = 106.227 + j3.095
m2
FREQUENCY = 1.000GHz
S(3,3) = 0.062/–119.363
IMPEDANCE = 93.526 – j10.208
m3
FREQUENCY = 2.000GHz
S(3,3) = 0.109/–125.024
IMPEDANCE = 86.866 – j15.742
