Voltage limit switch between electrode A and electrode C
„ „
Display
F
OUNDATION
Fieldbus
Block Relative
Name Index
DTB 68
DTB 69
DTB 70
DTB 71
DTB 72
Display
F
OUNDATION
Fieldbus
Block Relative
Name Index
DTB 73
DTB 74
DTB 75
DTB 76
DTB 77
--
Device Configuration ► DTB ► Device Configuration ► Configuration ► Limit Switch
Electrode A1 ► (see below)
Parameter
Display F
OUNDATION
Lim.Sw. Electrode A1 Value ►
--
Lmt Sts Elec A1.Status
Lim.Sw. Electrode A1 Value ►
--
Lmt Sts Elec A1.Value
-- Lmt Sts Elec A1 Sp
-- Lmt Sts Elec A1 Act Dir
-- Lmt Sts Elec A1 Hys
-- Lmt Sts Elec A1 Unit
--
Device Configuration ► DTB ► Device Configuration ► Configuration ► Limit Switch
Electrode A2 ► (see below)
Parameter
Display F
OUNDATION
Lim.Sw. Electrode A2 Value ►
--
Lmt Sts Elec A2.Status
Lim.Sw. Electrode A2 Value ►
--
Lmt Sts Elec A2.Value
-- Lmt Sts Elec A2 Sp
-- Lmt Sts Elec A2 Act Dir
-- Lmt Sts Elec A2 Hys
-- Lmt Sts Elec A2 Unit
<5. Functions>
Fieldbus
Displays the status of the contact point
output of voltage limit switch 1 between
electrode A and electrode C.
Displays the contact point output of
voltage limit switch 1 between electrode A
and electrode C.
Specifies the threshold of voltage limit
switch 1 between electrode A and
electrode C.
Specifies the operation direction of
voltage limit switch 1 between electrode A
and electrode C.
Specifies the hysteresis of voltage
limit switch 1 between electrode A and
electrode C.
Displays the unit of the voltage between
electrode A and electrode C.
Fieldbus
Displays the status of the contact point
output of voltage limit switch 2 between
electrode A and electrode C.
Displays the contact point output of
voltage limit switch 2 between electrode A
and electrode C.
Specifies the threshold of voltage limit
switch 2 between electrode A and
electrode C.
Specifies the operation direction of
voltage limit switch 2 between electrode A
and electrode C.
Specifies the hysteresis of voltage
limit switch 2 between electrode A and
electrode C.
Displays the unit of the voltage between
electrode A and electrode C.
