5.10.4 Test Mode Auto Reset

If the specified time lapses with no parameters changed while the test mode is enabled, the test
mode is reset automatically. When any test mode parameter is changed, the test mode reset time
is extended.
The setting can be configured with the following parameter.
Menu path
Display
F
OUNDATION
Fieldbus
Block Relative
Name Index
MTB 95
From the table below, select the test mode auto reset time.
Selection
Display
10 min
30 min
1 h
3 h
12 h
Device setup ► Diag/Service ► Test ► (see below)
Device Configuration ► MTB ► Device Configuration ► Query Device ► MaintTB Original
Parameters(Part2) ► Page 4 ► Test
Parameter
Display
Release time Test Auto Release Time
F
OUNDATION
Fieldbus
10min Sets the reset time to 10 min.
30min Sets the reset time to 30 min.
1h Sets the reset time to 1 hour.
3h Sets the reset time to 3 hours.
12h Sets the reset time to 12 hours.
<5. Functions>
F Fieldbus
OUNDATION
Description
143
Description
Specifies the time to
automatically reset the test
mode.
IM 01E21A02-03EN
