Danfoss VLT AutomationDrive FC 360 Programming Manual page 96

Parameter Descriptions
4.12.1 13-0* SLC Settings
Use the SLC settings to activate, deactivate, and reset the
smart logic control sequence. The logic functions and
comparators are always running in the background, which
opens for separate control of digital inputs and outputs.
13-00 SL Controller Mode
Option:
4 4
[0] Off
*
[1] On
13-01 Start Event
Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
*
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[83] Broken Belt
94
VLT
Function:
Disable the smart logic controller.
Enable the smart logic controller.
Danfoss A/S © 06/2017 All rights reserved.
®
AutomationDrive FC 360
13-02 Stop Event
Option:
[0]
[1]
[2]
[3]
[4]
[7]
[8]
[9]
[16]
[17]
[18]
Function:
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[39]
[40]
*
[42]
[50]
[51]
[60]
[61]
[70]
[71]
[72]
[73]
[74]
[83]
13-03 Reset SLC
Option:
[0] Do not reset
*
SLC
[1] Reset SLC
False
True
Running
In range
On reference
Out of current range
Below I low
Above I high
Thermal warning
Mains out of range
Reversing
Warning
Alarm (trip)
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL Time-out 0
SL Time-out 1
SL Time-out 2
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Start command
Drive stopped
Auto Reset Trip
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
SL Time-out 3
SL Time-out 4
SL Time-out 5
SL Time-out 6
SL Time-out 7
Broken Belt
Function:
Retain programmed settings in parameter
group 13-** Smart Logic.
Reset all parameters in parameter group 13-
** Smart Logic to default settings.
Function:
