Danfoss VLT AutomationDrive FC 360 Programming Manual page 131

Parameter Lists
5.2.2 1-** Load and Motor
Par. No. # Parameter description
1-0* General Settings
1-00 Configuration Mode
1-01 Motor Control Principle
1-03 Torque Characteristics
1-06 Clockwise Direction
1-08 Motor Control Bandwidth
1-1* Motor Selection
1-10 Motor Construction
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-2* Motor Data
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-29 Automatic Motor Adaption (AMA)
1-3* Adv. Motor Data I
1-30 Stator Resistance (Rs)
1-31 Rotor Resistance (Rr)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-4* Adv. Motor Data II
1-40 Back EMF at 1000 RPM
1-42 Motor Cable Length
1-43 Motor Cable Length Feet
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-48 Current at Min Inductance for d-axis
1-49 Current at Min Inductance for q-axis
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed
1-52 Min Speed Normal Magnetising [Hz]
1-55 U/f Characteristic - U
1-56 U/f Characteristic - F
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation
1-61 High Speed Load Compensation
1-62 Slip Compensation
1-63 Slip Compensation Time Constant
1-64 Resonance Dampening
1-65 Resonance Dampening Time Constant
MG06C702
Programming Guide
Default value
[0] Open Loop
+
[1] VVC
[0] Constant torque
[0] Normal
ExpressionLimit
[0] Asynchron
120%
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Off
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
50 m
164 ft
ExpressionLimit
ExpressionLimit
100%
100%
100%
100%
1 Hz
ExpressionLimit
ExpressionLimit
100%
100%
ExpressionLimit
0.1 s
100%
0.005 s
Danfoss A/S © 06/2017 All rights reserved.
2-set-up Change Conversio
during n index
operation
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE -2
All set-ups FALSE 67
All set-ups FALSE -1
All set-ups FALSE
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups FALSE -2
All set-ups FALSE -3
All set-ups FALSE -6
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -1
All set-ups FALSE -1
All set-ups FALSE -1
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE
All set-ups TRUE -3
Type
– Uint8
– Uint8
– Uint8
– Uint8
– Uint8
5 5
– Uint8
0 Int16
Uint16
Uint16
Uint16
– Uint8
0 Uint16
0 Uint16
Uint32
Uint16
Uint32
– Uint8
Uint32
Uint32
Uint32
Uint32
Int32
Int32
0 Uint8
0 Uint16
0 Uint8
0 Uint16
Int32
Int32
0 Uint16
0 Uint16
0 Uint16
0 Uint16
Uint16
Uint16
Uint16
0 Int16
0 Int16
0 Int16
Uint16
0 Uint16
Uint16
129
