Parameter Descriptions
7-45 Process PID Feed Fwd Resource
Option:
4 4
[0] No function
*
[1] Analog Input 53
[2] Analog Input 54
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
[32] Bus PCD
7-46 Process PID Feed Fwd Normal/ Inv. Ctrl.
Option:
[0] Normal Select [0] Normal to set the feed-forward factor to
*
[1] Inverse Select [1] Inverse to treat the feed-forward resource
7-48 PCD Feed Forward
Range:
0 [0 - 65535 ] Readout parameter where the bus
*
7-49 Process PID Output Normal/ Inv. Ctrl.
Option:
[0] Normal Select [0] Normal to use the resulting output from
*
[1] Inverse Select [1] Inverse to invert the resulting output
4.8.6 7-5* Ext. Process PID Ctrl.
This parameter group is only used if parameter 1-00 Config-
uration Mode is set to [7] Extended PID speed CL.
7-50 Process PID Extended PID
Option:
[0] Disabled Disable the extended parts of the process PID
[1] Enabled Enable the extended parts of the PID controller.
*
78
Function:
Select which frequency converter input
is used as the feed forward factor. The
FF factor is added directly to the
output of the PID controller. This
parameter can increase dynamic
performance.
The feed forward set from bus should
be in N2 format.
Function:
treat the FF resource as a positive value.
as a negative value.
Function:
parameter 7-45 Process PID Feed Fwd Resource
[32] can be read.
The feed forward set from bus should be in N2
format.
Function:
the process PID controller as is.
from the process PID controller. This operation is
performed after the feed-forward factor is applied.
Function:
controller.
Danfoss A/S © 06/2017 All rights reserved.
®
VLT AutomationDrive FC 360
7-51 Process PID Feed Fwd Gain
Range:
1 [0 -
*
100 ]
7-52 Process PID Feed Fwd Ramp up
Range:
0.01 s
*
7-53 Process PID Feed Fwd Ramp down
Range:
0.01 s
*
7-56 Process PID Ref. Filter Time
Range:
0.001 s
*
7-57 Process PID Fb. Filter Time
Range:
0.001 s
*
Function:
The feed forward is used to obtain the gain, based
on a well-known signal available. The PID controller
then only takes care of the smaller part of the
control, necessary because of unknown characters.
The standard feed-forward factor in
parameter 7-38 Process PID Feed Forward Factor is
always related to the reference whereas
parameter 7-51 Process PID Feed Fwd Gain has more
options. In winder applications, the feed-forward
factor is typically the line speed of the system.
Function:
[0.01 - 100 s] Control dynamics of the feed-forward
signal when ramping up.
Function:
[0.01 - 100 s] Control the dynamics of the feed-forward
signal when ramping down.
Function:
[0.001 - 1 Set a time constant for the reference first-
s] order low-pass filter. The low-pass filter
improves steady-state performance and
dampens oscillations on the reference/
feedback signals. However, severe filtering
can be detrimental to dynamic
performance.
Function:
[0.001 - 1 Set a time constant for the feedback first-
s] order low-pass filter. The low-pass filter
improves steady-state performance and
dampens oscillations on the reference/
feedback signals. However, severe filtering
can be detrimental to dynamic
performance.
