1.1 How to Read This Programming Guide

1.1.1 Purpose of the Manual
This programming guide provides information about
controlling the frequency converter, parameter access,
programming, and troubleshooting.
The programming guide is intended for use by qualified
personnel who are familiar with VLT
360.
Read the instructions before programming and follow the
procedures in this manual.
®
VLT is a registered trademark.
1.1.2 Additional Resources
Additional resources include:
•
®
VLT AutomationDrive FC 360 Quick Guide provide
the necessary information for getting the
frequency converter up and running.
•
®
VLT AutomationDrive FC 360 Design Guide
provides detailed technical information about the
frequency converter and customer design and
applications.
Contact the local Danfoss supplier or go to
www.danfoss.com/fc360 to download the documentations.
1.1.3 Document and Software Version
This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks
Update due to new software version
MG06C7
release.
Table 1.1 Document and Software Version
MG06C702
Programming Guide
®
AutomationDrive FC
Software
version
1.7x
