Parameter Descriptions
16-57 Feedback [RPM]
Range:
0 RPM [-30000 -
*
30000 RPM]
4 4
4.15.5 16-6* Inputs and Outputs
16-60 Digital Input
Range:
0 [0 -
*
65535 ]
16-61 Terminal 53 Setting
Option:
[0] Current mode
[1] Voltage mode
16-62 Analog input 53
Range:
1 [0 - 20 ]
*
16-63 Terminal 54 Setting
Option:
[0] Current mode
[1] Voltage mode
16-64 Analog input 54
Range:
1 [0 - 20 ]
*
16-65 Analog output 42 [mA]
Range:
0 mA [0 - 20
*
mA]
110
VLT
Function:
Readout parameter where the actual motor
RPM from the feedback source can be read
in both closed loop and open loop. The
feedback source is selected in
parameter 7-00 Speed PID Feedback Source.
Function:
View the actual state of the digital inputs 18, 19,
27, and 29.
Bit 0 Digital input terminal 33
Bit 1 Digital input terminal 32
Bit 2 Digital input terminal 29
Bit 3 Digital input terminal 27
Bit 4 Digital input terminal 19
Bit 5 Digital input terminal 18
Bit 10 Digital input terminal 31
Table 4.11 Bits Definition
Function:
View the setting of input terminal 53.
Function:
View the actual value at input 53.
Function:
View the setting of input terminal 54.
Function:
View the actual value at input 54.
Function:
View the actual value at output 42. The
value shown reflects the selections in
parameter 6-90 Terminal 42 Mode and
parameter 6-91 Terminal 42 Analog Output.
Danfoss A/S © 06/2017 All rights reserved.
®
AutomationDrive FC 360
16-66 Digital Output
Range:
0 [0 - 15 ] View the binary value of all digital outputs.
*
16-67 Pulse input 29 [Hz]
Range:
0 [0 - 130000 ] View the actual frequency rate on terminal 29.
*
16-68 Pulse input 33 [Hz]
Range:
0 [0 - 130000 ] View the actual value of the frequency
*
16-69 Pulse output 27 [Hz]
Range:
0 [0 - 40000 ] View the actual value of impulses applied to
*
16-70 Pulse output 29 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses to terminal 29
*
16-71 Relay output
Range:
0 [0 - 65535 ] View the settings of all relays.
*
16-72 Counter A
Range:
0 [-32768 -
*
32767 ]
Function:
Bit 2 Digital output terminal 29
Bit 3 Digital output terminal 27
Bit 4 Digital output terminal 45
Bit 5 Digital output terminal 42
Table 4.12 Bits Definition
Function:
Function:
applied at terminal 33 as an impulse input.
Function:
terminal 27 in digital output mode.
Function:
in digital output mode.
Function:
Bit 3 User relay 02
Bit 4 User relay 01
Table 4.13 Bits Definition
Function:
View the present value of counter A. Counters are
useful as comparator operands, see
parameter 13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital Inputs),
or by using an SLC action (parameter 13-52 SL
Controller Action).
MG06C702
