Parameter Lists
5.2.17 18-** Data Readouts 2
Par. Parameter description
No. #
18-8* Center Winder Readout
18-81 Tension PID Output
18-82 Center Winder Output
18-83 Line Speed
18-84 Diameter
18-85 Tapered Tension Set Point
5 5
18-86 Tension Feedback
18-9* PID Readouts
18-90 Process PID Error
18-91 Process PID Output
18-92 Process PID Clamped Output
18-93 Process PID Gain Scaled Output
5.2.18 21-** Ext. Closed Loop
Par. Parameter description
No. #
21-0* Ext. CL Autotuning
21-09 Extended PID Enable
21-1* Ext. CL 1 Ref./Fb.
21-11 Ext. 1 Minimum Reference
21-12 Ext. 1 Maximum Reference
21-13 Ext. 1 Reference Source
21-14 Ext. 1 Feedback Source
21-15 Ext. 1 Setpoint
21-17 Ext. 1 Reference [Unit]
21-18 Ext. 1 Feedback [Unit]
21-19 Ext. 1 Output [%]
Ext. CL 1 PID
21-20 Ext. 1 Normal/Inverse Control
21-21 Ext. 1 Proportional Gain
21-22 Ext. 1 Integral Time
21-23 Ext. 1 Differentiation Time
21-24 Ext. 1 Dif. Gain Limit
144
®
VLT AutomationDrive FC 360
Default value
0 Hz
0 Hz
0 Hz
0%
0%
0%
0%
0%
0%
0%
Default value
[0] Disabled
0 ExtPID1Unit
100 ExtPID1Unit
[0] No function
[0] No function
0 ExtPID1Unit
0 ExtPID1Unit
0 ExtPID1Unit
0%
[0] Normal
0.01 N/A
10000 s
0 s
5 N/A
Danfoss A/S © 06/2017 All rights reserved.
4-set-up Change
during
operation
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
4-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conversion Type
index
-3 Int32
-3 Int32
-3 Int32
-3 Int32
-1 Int32
-1 Int32
-1 Int16
-1 Int16
-1 Int16
-1 Int16
Conversion Type
index
- Uint8
-3 Int32
-3 Int32
- Uint8
- Uint8
-3 Int32
-3 Int32
-3 Int32
0 Int32
- Uint8
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
