Parameter Descriptions
4-57 Warning Feedback High
Range:
4999 [-4999 - 4999
ProcessCtrlUnit ProcessCtrlUnit]
*
4-58 Missing Motor Phase Function
Option: Function:
[0] Off No alarm is shown if a missing motor phase occurs.
[1] On An alarm is shown if a missing motor phase occurs.
*
4.5.6 4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
Range: Function:
0 Hz [ 0 - Some systems call for avoiding certain output
*
500 Hz] speeds due to resonance problems in the
system. Enter the lower limits of the speeds to
be avoided.
The bypass speed from must not exceed the
setting in parameter 4-14 Motor Speed High Limit
[Hz].
4-63 Bypass Speed To [Hz]
Range: Function:
0 Hz [ 0 - Some systems call for avoiding certain output
*
500 Hz] speeds due to resonance problems in the
system. Enter the upper limits of the speeds to
be avoided.
The bypass speed to must not exceed the
setting in parameter 4-14 Motor Speed High Limit
[Hz].
MG06C702
Programming Guide
Function:
Use this parameter to set a
high limit for the feedback
range. When the feedback
exceeds this limit, the display
reads Feedb High. Bit 5 is set
in parameter 16-94 Ext. Status
Word. The output relay or the
digital output can be
configured to indicate this
warning. The LCP warning
light is not turned on when
this parameter set limit is
reached.
Danfoss A/S © 06/2017 All rights reserved.

4.6 Parameters: 5-** Digital In/Out

4.6.1 5-0* Digital I/O Mode
Parameters for configuring the input and output using
NPN and PNP.
5-00 Digital Input Mode
Option: Function:
Set NPN or PNP mode for digital inputs.
NOTICE
This parameter cannot be adjusted while the
motor runs.
[0] PNP Action on positive directional pulses (0). PNP systems
*
are pulled down to ground (GND).
[1] NPN Action on negative directional pulses (1). NPN
systems are pulled up to +24 V, internally in the
frequency converter.
5-01 Terminal 27 Mode
Option: Function:
[0] Input Define terminal 27 as a digital input.
*
[1] Output Define terminal 27 as a digital output.
5-02 Terminal 29 Mode
Option: Function:
[0] Input Defines terminal 29 as a digital input.
*
[1] Output Defines terminal 29 as a digital output.
The digital inputs are used for selecting various functions
in the frequency converter.
5-10 to 5-16 Digital Inputs
[0] No No reaction to signals transmitted to the
operation terminal.
[1] Reset Resets frequency converter after a TRIP/ALARM.
Not all alarms can be reset.
[2] Coast Coasting stop, inverted input (NC). The
inverse frequency converter leaves the motor in free
mode.
Logic 0⇒ coasting stop.
[3] Coast and Reset and coasting stop inverted input (NC).
reset Leaves motor in free mode and resets
inverse frequency converter.
Logic 0⇒coasting stop.
Logic 1 to Logic 0⇒reset.
[4] Quick stop Inverted input (NC). Generates a stop in
inverse accordance with the quick stop ramp time set
in parameter 3-81 Quick Stop Ramp Time. When
the motor stops, the shaft is in free mode.
Logic 0⇒ Quick-stop.
[5] DC-brake Inverted input for DC braking (NC). Stops the
inverse motor by energizing it with a DC current for a
4 4
