Parameter Descriptions
9-28 Process Control
Option:
Function:
Process control (setting of control word, speed
reference, and process data) is possible via either
PROFIBUS or standard fieldbus, but not both
simultaneously. Local control is always possible via
the LCP. Control via process control is possible via
either terminals or fieldbus depending on the
settings in parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
[0]
Disable
Disables process control via PROFIBUS master
class 1 and enables process control via standard
fieldbus or PROFIBUS master class 2.
[1]
Enable
Enables process control via PROFIBUS master class
cyclic
1 and disables process control via standard
*
master
fieldbus or PROFIBUS master class 2.
9-44 Fault Message Counter
Range:
Function:
0
[0 -
Indicates the number of fault events presently
*
65535 ]
stored in parameter 9-45 Fault Code. The buffer
capacity is maximum 8 error events. The buffer
and counter are set to 0 by reset or power-up.
9-45 Fault Code
Range:
Function:
0
[0 - 0 ] This buffer contains the alarm word for all alarms
*
and warnings that have occurred since last reset or
power-up. The buffer capacity is maximum 8 error
events.
9-47 Fault Number
Range:
Function:
0
[0 - 0 ] This buffer contains the alarm word for all alarms
*
and warnings that have occurred since last reset or
power-up. The buffer capacity is maximum 8 error
events.
9-52 Fault Situation Counter
Range:
Function:
0
[0 - 1000 ] Indicates the number of fault events that have
*
occurred since last reset or power-up.
MG06C702
Programming Guide
9-53 Profibus Warning Word
Range:
0
[0 -
*
65535 ]
9-63 Actual Baud Rate
Option:
[0]
[1]
[2]
[3]
[4]
[6]
[7]
[8]
[9]
[10]
[11]
[255]
*
Danfoss A/S © 06/2017 All rights reserved.
Function:
This parameter shows PROFIBUS communication
warnings.
Bit
Description
0
Connection with DP master is lost.
1
Not used.
2
FDL (fieldbus data link layer) is not
OK.
3
Clear data command received.
4
Actual value is not updated.
5
Baud rate search.
6
PROFIBUS ASIC is not transmitting.
7
Initializing of PROFIBUS is not OK.
8
Frequency converter is tripped.
9
Internal CAN error.
10
Wrong configuration data from PLC.
11
Wrong ID sent by PLC.
12
Internal fault occurred.
13
Not configured.
14
Timeout active.
15
Warning 34 active.
Table 4.8 Bit Definition
Function:
This parameter shows the actual
PROFIBUS baud rate. The PROFIBUS
master automatically sets the baud
rate.
9,6 kbit/s
19,2 kbit/s
93,75 kbit/s
187,5 kbit/s
500 kbit/s
1500 kbit/s
3000 kbit/s
6000 kbit/s
12000 kbit/s
31,25 kbit/s
45,45 kbit/s
No baudrate found
4
4
87
