Parameter Descriptions
16-73 Counter B
Range: Function:
0 [-32768 - View the present value of counter B. Counters are
*
32767 ] useful as comparator operands
(parameter 13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital Inputs)
or by using an SLC action (parameter 13-52 SL
Controller Action).
16-79 Analog output 45 [mA]
Range: Function:
0 mA [0 - 20 View the actual value at output 45 in mA.
*
mA] The value shown reflects the selection in
parameter 6-70 Terminal 45 Mode and
parameter 6-71 Terminal 45 Analog Output.
4.15.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 [0 - View the 2-byte control word (CTW) received
*
65535 ] from the bus master. Interpretation of the CTW
depends on the fieldbus option installed and the
CTW profile selected in parameter 8-10 Control
Word Profile. For more information, see relevant
fieldbus manuals.
16-82 Fieldbus REF 1
Range: Function:
0 [-32768 - To set the reference value, view the 2-byte
*
32767 ] word sent with the control word from the
bus master. For more information, refer to
the relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] View the extended fieldbus communication
*
option status word. For more information, refer
to the relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
1084 [0 - View the 2-byte control word (CTW) received
*
65535 ] from the bus master. Interpretation of the
control word depends on the fieldbus option
installed and the control word profile
selected in parameter 8-10 Control Word
Profile.
MG06C702
Programming Guide
16-86 FC Port REF 1
Range:
0 [-32768 - 32767 ] View the last received reference from the
*
4.15.7 16-9* Diagnosis Readouts
Use the parameters to display alarm, warning, and
extended status words.
16-90 Alarm Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
*
16-92 Warning Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word sent via the
*
16-93 Warning Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 0xFFFFFFFFUL ] Return the extended status word sent
*
16-95 Ext. Status Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] Return the extended status word 2 sent
*
16-97 Alarm Word 3
Range:
0 [0 - 0xFFFFFFFFUL ] Show the alarm word 3 sent via the
*
Danfoss A/S © 06/2017 All rights reserved.
Function:
FC port.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
via the serial communication port in
hex code.
Function:
via the serial communication port in
hex code.
Function:
serial communication port in hex code.
