Parameter Descriptions
16-16 Torque [Nm]
Range: Function:
0 Nm [-30000 - View the torque value with sign, applied to
30000 Nm] the motor shaft. Some motors supply more
than 160% torque. As a result, the minimum
value and the maximum value depend on
the maximum motor current as well as the
motor used.
16-17 Speed [RPM]
Range: Function:
0 RPM [-30000 - View the actual motor RPM. In open-loop
30000 RPM] or closed-loop process control, the motor
RPM is estimated. In speed closed-loop
modes, the motor RPM is measured.
16-18 Motor Thermal
Range: Function:
0 % [0 - View the calculated thermal load on the motor.
*
100 %] The cutout limit is 100%. The basis for
calculation is the ETR function selected in
parameter 1-90 Motor Thermal Protection.
16-22 Torque [%]
Range: Function:
0 % [ -200– 200 % ] View the torque in percent of nominal
*
torque, with sign, applied to the motor
shaft.
4.15.3 16-3* Drive Status
16-30 DC Link Voltage
Range: Function:
0 V [0 - 65535 V] View a measured value. The value is filtered
*
with a 128 ms time constant.
16-33 Brake Energy Average
Range: Function:
0 kW [0 - 10000 View the brake power transmitted to an
*
kW] external brake resistor. The mean power is
calculated on an average level based on
the latest 120 s.
16-34 Heatsink Temp.
Range: Function:
0 °C [-128 - View the frequency converter heat sink
*
temperature. The cutout limit is 90 ±5 °C
127 °C]
[194 °F], and the motor cuts back in at 60
±5 °C [140 °F].
16-35 Inverter Thermal
Range: Function:
0 % [0 - 255 %] View the percentage load on the inverter.
*
MG06C702
Programming Guide
16-36 Inv. Nom. Current
Range:
0 A [0 - 655.35 A] View the inverter nominal current, which
*
16-37 Inv. Max. Current
Range:
0 A [0 - 655.35 A] View the inverter maximum current, which
*
16-38 SL Controller State
Range:
0 [0 - 20 ] View the state of the event under execution by
*
16-39 Control Card Temp.
Range:
0 °C
*
4.15.4 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0 %
*
200 %]
16-52 Feedback[Unit]
Range:
0
ProcessCtrlUnit
16-53 Digi Pot Reference
Range:
0 [-200 - 200 ] View the contribution of the digital potenti-
*
Danfoss A/S © 06/2017 All rights reserved.
Function:
should match the nameplate data on the
connected motor. The data is used for
calculation of torque and motor protection.
Function:
should match the nameplate data on the
connected motor. The data is used for
calculation of torque and motor protection.
Function:
the SL controller.
Function:
[0 - 65535 °C] View the temperature on the control card,
stated in °C.
Function:
[-200 - View the total reference, the sum of digital,
analog, preset, bus, and freeze references,
plus catch up and slow down.
Function:
[-4999 - 4999 View the feedback unit
ProcessCtrlUnit] resulting from the selection
*
of unit and scaling in
parameter 3-00 Reference
Range,
parameter 3-01 Reference/
Feedback Unit,
parameter 3-02 Minimum
Reference, and
parameter 3-03 Maximum
Reference.
Function:
ometer to the actual reference.
