Parameter Descriptions
Fault Reason for details about the fault.
This option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[173] Position Mech Selects mechanical control for positioning.
Brake This option is only effective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[174] TLD indicator Indicates whether the tension is out of
limit (on) during center winding. This
option is only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
[175] Running on Indicates whether tension PID control is
tension active (on) or inactive (off). This option is
only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
[176] Ready to run The center winder control is ready to run.
This option is only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
[177] End of roll The diameter limit is reached. This option
is only effective when
parameter 37-00 Application Mode is set to
[1] Center winder.
[193] Sleep mode The frequency converter/system has
entered sleep mode. See parameter group
22-4* Sleep Mode.
[194] Broken belt A broken belt condition has been
detected. See parameter group 22-4* Sleep
Mode.
5-30 Terminal 27 Digital Output
Option: Function:
[0] No operation Functions are described in parameter group
*
5-3* Digital Outputs.
5-31 Terminal 29 Digital Output
Option: Function:
[0] No operation Functions are described in parameter group
*
5-3* Digital Outputs.
5-34 On Delay, Digital Output
Range:
0.01 s [0 - 600 s]
*
5-35 Off Delay, Digital Output
Range:
0.01 s [0 - 600 s]
*
MG06C702
Programming Guide
4.6.3 5-4* Relays
Parameters for configuring the timing and the output
functions for the relays.
The parameter is an array parameter representing 2 relays:
Array [2] (Relay 1 [0], Relay 2 [1]).
5-40 Function Relay
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
Function:
[13]
[14]
Function:
[15]
[16]
Danfoss A/S © 06/2017 All rights reserved.
Function:
No operation Default setting for all digital and relay
outputs.
Control Ready The control card is ready.
Drive ready The frequency converter is ready to
operate. Mains and control supplies are
OK.
Drive rdy/rem ctrl The frequency converter is ready for
operation, and is in auto-on mode.
Stand-by / no Ready for operation. No start or stop
warning commands have been applied. No
warnings are active.
Running The motor is running and a shaft
torque is present.
Running / no The motor is running and no warnings
warning are present.
Run in range/no The motor is running within the
warn programmed current ranges set in
parameter 4-50 Warning Current Low.
Run on ref/no The motor runs at reference speed. No
warn warnings.
Alarm An alarm activates the output.
Alarm or warning An alarm or warning activates the
output.
At torque limit The torque limit set in
parameter 4-16 Torque Limit Motor Mode
or parameter 4-17 Torque Limit
Generator Mode has been exceeded.
Out of current The motor current is outside the range
range set in parameter 4-18 Current Limit.
Below current, The motor current is lower than set in
parameter 4-50 Warning Current Low.
low
Above current, The motor current is higher than set in
high parameter 4-51 Warning Current High.
Out of frequency The output speed/frequency exceeds
range the limit that is set in
parameter 4-40 Warning Freq. Low and
parameter 4-41 Warning Freq. High.
Below frequency, The output frequency is lower than the
low setting in parameter 4-40 Warning Freq.
Low.
4 4
63
