Programming
B. Display menu keys
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Key
6 Status Shows operational information.
Allows access to programming parameters
Quick
7 for initial set-up instructions and many
Menu
detailed application instructions.
Allows access to all programming
8 Main Menu
parameters.
Shows a list of current warnings, the last 10
9 Alarm Log
alarms, and the maintenance log.
Table 3.9 Legend to Illustration 3.9, Display Menu Keys
C. Navigation keys and indicator lights (LEDs)
Navigation keys are used for programming functions and
moving the display cursor. The navigation keys also
provide speed control in local operation. There are also 3
frequency converter status indicator lights in this area.
Key
Reverts to the previous step or list in the
10 Back
menu structure.
Cancels the last change or command as long
11 Cancel
as the display mode has not changed.
Press for a definition of the function being
12 Info
shown.
Navigation To move between items in the menu, use the
13
keys 4 navigation keys.
Press to access parameter groups or to
14 OK
enable a selection.
Table 3.10 Legend to Illustration 3.9, Navigation Keys
Indicator Light
ON turns on when the frequency
converter receives power from the
15 On Green
mains voltage or a DC bus
terminal.
When warning conditions are met,
the yellow WARN LED turns on,
16 Warn Yellow
and text appears in the display
area identifying the problem.
A fault condition causes the red
17 Alarm Red alarm LED to flash, and an alarm
text is shown.
Table 3.11 Legend to Illustration 3.9, Indicator Lights (LEDs)
D. Operation keys and reset
Operation keys are at the bottom of the LCP.
MG06C702
Programming Guide
Function
Function
Function
Danfoss A/S © 06/2017 All rights reserved.
Key
Starts the frequency converter in hand-on
mode.
•
An external stop signal by control input
18 Hand On
or serial communication overrides the
local hand on.
Stops the motor but does not remove power
19 Off
to the frequency converter.
Puts the system in remote operational mode.
•
Responds to an external start command
20 Auto On
by control terminals or serial communi-
cation.
Resets the frequency converter manually
21 Reset
after a fault has been cleared.
Table 3.12 Legend to Illustration 3.9, Operation Keys and Reset
NOTICE
To adjust the display contrast, press [Status] and the
▲ ▼
[ ]/[ ] keys.
3.1.7 Changing Parameter Settings with
GLCP
Access and change parameter settings from the Quick
Menu or from the Main Menu. The Quick Menu only gives
access to a limited number of parameters.
1. Press [Quick Menu] or [Main Menu] on the LCP.
▲ ▼
2.
Press [ ] [ ] to browse through the parameter
groups, press [OK] to select a parameter group.
▲ ▼
3.
Press [ ] [ ] to browse through the parameters,
press [OK] to select a parameter.
▲ ▼
4. Press [ ] [ ] to change the value of a parameter
setting.
5. Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter Status, or press
[Main Menu] once to enter the Main Menu.
View changes
Quick Menu Q5 - Changes Made lists all parameters
changed from default settings.
•
The list only shows parameters, which have been
changed in the current edit set-up.
•
Parameters which have been reset to default
values are not listed.
•
The message Empty indicates that no parameters
have been changed.
