Parameter Descriptions
4.8.7 7-6* Feedback Conversion
Use the parameter group to configure conversions for
feedback signals.
7-60 Feedback 1 Conversion
Select a conversion for the feedback 1 signal. Select [0] Linear to
leave the feedback signal unchanged.
Option:
[0] Linear
*
[1] Square root
7-62 Feedback 2 Conversion
Select a conversion for the feedback 2 signal. Select [0] Linear to
leave the feedback signal unchanged.
Option:
[0] Linear
*
[1] Square root
4.9 Parameters: 8-** Communications and
Options
4.9.1 8-0* General Settings
8-01 Control Site
Option: Function:
The setting in this parameter overrides
the settings in parameter 8-50 Coasting
Select to parameter 8-56 Preset Reference
Select.
[0] Digital and Control by using both digital input and
*
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Source
Option: Function:
Select the source of the control word.
[0] None
[1] FC Port
[3] Option A PROFIBUS and PROFINET.
8-03 Control Timeout Time
Range: Function:
1 s [0.1 - Enter the maximum time expected to pass
*
6000 s] between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the serial communication has stopped. The
function that is selected in
parameter 8-04 Control Timeout Function is then
carried out.
MG06C702
Programming Guide
8-04 Control Timeout Function
Select the timeout function. The timeout function activates when
the control word fails to be updated within the time period
specified in parameter 8-03 Control Word Timeout Time.
Option:
[0]
Function:
[1]
[2]
[3]
Function:
[4]
[5]
8-07 Diagnosis Trigger
Option:
[0]
[1]
[2]
4.9.2 8-1* Ctrl. Word Settings
8-10 Control Word Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the installed fieldbus are visible in the LCP display.
Option:
[0]
[1]
8-14 Configurable Control Word CTW
Option:
[0]
[1]
[2]
[4]
[5]
[6]
Danfoss A/S © 06/2017 All rights reserved.
Function:
Off Resume control via fieldbus (fieldbus or
*
standard), using the most recent control
word.
Freeze output Freeze output frequency until communi-
cation resumes.
Stop Stop with auto restart until communication
resumes.
Jogging Run the motor at jog frequency until
communication resumes.
Max. speed Run the motor at maximum frequency until
communication resumes.
Stop and trip Stop the motor and trip, then reset the
frequency converter to restart:
•
Via the fieldbus.
•
Via [Reset].
•
Via a digital input.
Function:
Disable Send no extended diagnosis data (EDD).
*
Trigger on Send EDD upon alarms.
alarms
Trigger Send EDD upon alarms or warnings in
alarm/warn. parameter 16-90 Alarm Word,
parameter 9-53 Profibus Warning Word, or
parameter 16-92 Warning Word.
FC profile
*
PROFIdrive profile
None
Profile default
*
CTW Valid, active low
PID error inverse
PID reset I part
PID enable
