Parameter Lists
5.2.13 14-** Special Functions
Par. No. # Parameter description
14-0* Inverter Switching
14-01 Switching Frequency
14-03 Overmodulation
14-07 Dead Time Compensation Level
14-08 Damping Gain Factor
14-09 Dead Time Bias Current Level
14-1* Mains On/Off
5 5
14-10 Mains Failure
14-11 Mains Voltage at Mains Fault
14-12 Function at Mains Imbalance
14-15 Kin. Backup Trip Recovery Level
14-2* Reset Functions
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-24 Trip Delay at Current Limit
14-25 Trip Delay at Torque Limit
14-27 Action At Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-32 Current Lim Ctrl, Filter Time
14-4* Energy Optimising
14-40 VT Level
14-41 AEO Minimum Magnetisation
14-44 d-axis current optimization for IPM
14-5* Environment
14-50 RFI Filter
14-51 DC-Link Voltage Compensation
14-52 Fan Control
14-55 Output Filter
14-6* Auto Derate
14-61 Function at Inverter Overload
14-63 Min Switch Frequency
Dead Time Compensation Zero
14-64 Current Level
Speed Derate Dead Time Compen-
14-65 sation
14-8* Options
14-89 Option Detection
14-9* Fault Settings
14-90 Fault Level
140
®
VLT AutomationDrive FC 360
Default value
ExpressionLimit
[1] On
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] No function
342 V
[0] Trip
ExpressionLimit
[0] Manual reset
10 s
[0] Normal operation
60 s
60 s
[1] Warning
[0] No action
0 N/A
100%
0.020 s
5 ms
66%
66%
100%
[2] Grid Type
[1] On
[5] Constant-on mode
[0] No Filter
[0] Trip
[2] 2.0 kHz
[0] Disabled
ExpressionLimit
[0] Protect Option
Config.
[3] Trip Lock
