Danfoss VLT AutomationDrive FC 360 Programming Manual page 124

Parameter Descriptions
37-23 Partial Roll Diameter Value
Range:
5 % [5 -
*
100 %]
4 4
37-24 Core1 Diameter
Range:
5 % [5 -
*
100 %]
37-25 Core2 Diameter
Range:
5 % [5 - 100 %] Set a secondary core diameter for winding
*
37-26 Winder Jog Speed
Range:
0 % [0 - 100 %] Set the winder jog speed percentage. This
*
37-27 TLD Low Limit
Range:
0 % [0 - 100 %] Set the low limit for the tension limit
*
37-28 TLD High Limit
Range:
0 % [0 - 100 %] Set the high limit for the tension limit
*
37-29 TLD Timer
Range:
0.001 s [0.001 - 5 s] Set the time within which the tension
*
122
VLT
Function:
Preset the diameter when a partial roll is loaded
on the winder. If Input 4 is ON when the
diameter is reset with Input 8, the diameter is
preset to the value programmed in this
parameter. For unwinding applications, use this
parameter to set the full roll diameter.
Function:
Set the main core value to be used on the
winder. This parameter must be set for the
smallest core diameter for both winding and
unwinding applications.
NOTICE
The value of parameter 37-24 Core1
Diameter must be less than
parameter 37-25 Core2 Diameter.
Function:
applications, or a secondary full roll diameter
for unwinding applications.
Function:
percentage value is used for both forward
and reverse jogging speed.
Function:
detection.
Function:
detection.
Function:
must exceed the high or low tension
limit.
Danfoss A/S © 06/2017 All rights reserved.
®
AutomationDrive FC 360
37-30 TLDOnDelay
Enable this parameter to allow time for the winder to stabilize
the web tension. When the tension moves within the low and
high tension limits, the TLD function begins operating normally.
This function can be useful during a quick machine start with a
slack web. This function is only active while running.
Option:
[0]
[1]
*
37-31 Diameter Limit Detector
Range:
100 % [0 -
*
100 %]
37-32 Initial Diameter Measurement
It is possible to connect a roll diameter sensor to one of the
frequency converter analog inputs. This signal can be used to
make the controller use a measured initial diameter, rather than a
diameter size set by parameters.
Option:
[0] Set diameter
*
when diameter
reset
[1] Set diameter
based on analog
signal
37-33 Diameter Measurement Input
Set the analog input used for diameter measurement.
Option:
[0] No Function
*
[1] Input53(0~10 VDC or 0~20 mA )
[2] Input54(0~10 VDC or 0~20 mA )
37-34 Reading at Core
Range:
0 [0 - 10 ] Set the analog input signal reading at the smallest
*
37-35 Reading at Full Roll
Range:
0 V [0 - 20 V] Set the analog input signal reading at the full
*
Function:
Disabled
Enabled
Function:
When the calculated roll diameter reaches
the set diameter, the corresponding digital
output is turned on to indicate the end of
the roll. This indicates a full roll when
winding and an empty roll when unwinding.
Function:
Set the diameter in
parameter 37-23 Partial Roll
Diameter Value to
parameter 37-25 Core2 Diameter
when the diameter is reset.
The frequency converter sets the
diameter based on an analog
signal. The diameter can only be
reset when the tension is OFF.
Function:
core used.
Function:
roll size used.
Function:
