Introduction

1.3 Electrical Wiring - Control Cables

1.3.1 Overview
RFI
91 (L1)
3 phase
92 (L2)
power
93 (L3)
input
95
50 (+10 V OUT)
+10 V DC
0-10 V DC
53 (A IN)
0/4-20 mA
0-10 V DC
54 (A IN)
0/4-20 mA
55 (COM A IN/OUT)
42 (A OUT)
Analog
output
0/4-20 mA
45 (A OUT)
12 (+24 V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27 (D IN/OUT)
29 (D IN/OUT)
31 (D IN)
32 (D IN)
33 (D IN)
Illustration 1.2 Basic Wiring Schematic Drawing
A=Analog, D=Digital
1) Built-in brake chopper available from J1–J5.
2) Relay 2 is 2-pole for J1–J3 and 3-pole for J4–J7. Relay 2 of J4–J7 with terminals 4, 5, and 6 has same NO/NC logic as relay 1.
Relays are pluggable in J1–J5 and fixed in J6–J7.
MG06C702
Programming Guide
3)
PE
Switch Mode
Power Supply
10 V DC
15 mA
+ -
P 5-00
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
Danfoss A/S © 06/2017 All rights reserved.
(-UDC) 88
1)
24 V DC
(+UDC) 89
100 mA
+ -
(BR) 81 5)
Relay 1
Relay 2 2)
4)
ON=Terminated
OFF=Open
5V
S801
RS485
(N RS485)
Interface
(P RS485)
0 V
(COM RS485) 61
(U) 96
(V) 97
(W) 98
(PE) 99
Motor
Brake
resistor
03
250 V AC, 3 A
02
01
06
250 V AC, 3 A
05
04
0V
RS485
69
68
(PNP) = Source
(NPN) = Sink
1 1
