Parameter Descriptions
13-52 SL Controller Action
Option: Function:
[10] Select preset Select preset reference 0. If the active preset
ref 0 reference is changed, it merges with other
preset reference commands coming from
either the digital inputs or via a fieldbus.
[11] Select preset Selects preset reference 1. If the active
ref 1 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[12] Select preset Selects preset reference 2. If the active
ref 2 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[13] Select preset Selects preset reference 3. If the active
ref 3 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[14] Select preset Selects preset reference 4. If the active
ref 4 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[15] Select preset Selects preset reference 5. If the active
ref 5 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[16] Select preset Selects preset reference 6. If the active
ref 6 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[17] Select preset Selects preset reference 7. If the active
ref 7 preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs, or via a
fieldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the frequency
converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the frequency
converter.
[25] Qstop Issues a quick stop command to the
frequency converter.
MG06C702
Programming Guide
13-52 SL Controller Action
Option:
[26] DC Brake
[27] Coast
[28] Freeze output Freezes the output of the frequency
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital
out A low
[33] Set digital
out B low
[34] Set digital
out C low
[35] Set digital
out D low
[38] Set digital
out A high
[39] Set digital
out B high
[40] Set digital
out C high
[41] Set digital
out D high
[60] Reset
Counter A
[61] Reset
Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
Danfoss A/S © 06/2017 All rights reserved.
Function:
Issues a DC-brake command to the
frequency converter.
The frequency converter coasts immediately.
All stop commands including the coast
command stop the SLC.
converter.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
Any output with SL output A is low.
Any output with SL output B is low.
Any output with SL output C is low.
Any output with SL output D is low.
Any output with SL output A is high.
Any output with SL output B is high.
Any output with SL output C is high.
Any output with SL output D is high.
Resets Counter A to zero.
Resets Counter B to zero.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
