Troubleshooting
Numb
Description
er
47 24 V supply low
50 AMA calibration
51 AMA check U and I
nom nom
52 AMA low I
nom
53 AMA big motor
54 AMA small motor
55 AMA parameter range
56 AMA interrupt
57 AMA timeout
58 AMA internal
59 Current limit
60 External Interlock
61 Feedback error
63 Mechanical brake low
65 Control card temp
69 Power card temp
70 Illegal FC config
Frequency converter initialized
80
to default value
87 Auto DC brake
90 Feedback monitor
95 Broken belt
99 Locked rotor
Flow/pressure information
101
missing
120 Position control fault
124 Tension limit
126 Motor rotating
127 2)
Back EMF too high
250 New spare part
251 New type code
Table 6.2 Warnings and Alarms Code List
1) These faults may be caused by mains distortions. Installing a Danfoss line filter may rectify this problem.
2) For enclosure size J7, the warning can also be caused by high UDC voltage.
MG06C702
Programming Guide
Warning Alarm Trip lock
X X X
– X –
– X –
– X –
– X –
– X –
– X –
– X –
– X –
– X –
X X –
– X –
X X –
– X –
X X X
X X X
– X X
– X –
X – –
X X –
X X –
– X –
– X X
– X –
– X –
– X –
X – –
– X X
– X X
Danfoss A/S © 06/2017 All rights reserved.
Cause
24 V DC may be overloaded.
–
Wrong setting for motor voltage and/or motor current.
Motor current is too low. Check the settings.
The power size of the motor is too large for the AMA to
operate.
The power size of the motor is too small for the AMA to
operate.
The parameter values of the motor are outside of the
acceptable range. AMA does not run.
The AMA is interrupted.
–
Contact Danfoss.
Frequency converter overload.
–
–
Actual motor current has not exceeded release brake
current within start delay time window.
The cutout temperature of the control card is 80 °C
(176 °F).
–
–
All parameter settings are initialized to default settings.
Occurs in IT mains when the frequency converter coasts
and the DC voltage are higher than 830 V. Energy on DC-
link is consumed by the motor. This function can be
enabled/disabled in parameter 0-07 Auto DC Braking.
A feedback fault is detected by option B.
–
–
–
–
–
–
Try to start PM motor which is rotating in an abnormal
high speed.
–
–
