Parameter Descriptions
4.4.5 3-6* Ramp 3
This parameter group configures ramp 3 parameters.
3-60 Ramp 3 Type
Option:
4 4
[0] Linear
*
[2] Sine 2
Ramp
3-61 Ramp 3 Ramp up Time
Range:
Size [0.01 -
related 3600 s]
*
3-62 Ramp 3 Ramp down Time
Range:
Size [0.01 -
related 3600 s]
*
4.4.6 3-7* Ramp 4
This parameter group configures ramp 4 parameters.
3-70 Ramp 4 Type
Option:
[0] Linear
*
52
VLT
Function:
Select the ramp type, depending on
requirements for acceleration/deceleration. A
linear ramp gives constant acceleration during
ramping. An S-ramp gives non-linear
acceleration.
S-ramp based on the values set in
parameter 3-61 Ramp 3 Ramp up Time and
parameter 3-62 Ramp 3 Ramp down Time.
Function:
Enter the ramp-up time, which is the
acceleration time from 0 Hz to the rated
motor speed n . Select a ramp-up time
s
such that the output current does not
exceed the current limit in
parameter 4-18 Current Limit during
ramping. See ramp-down time in
parameter 3-62 Ramp 3 Ramp down Time.
Function:
Enter the ramp-down time, which is the
deceleration time from the rated motor
speed n to 0 Hz. Select a ramp-down time
s
such that no overvoltage arises in the
inverter due to regenerative operation of the
motor, and such that the generated current
does not exceed the current limit set in
parameter 4-18 Current Limit. See ramp-up
time in parameter 3-61 Ramp 3 Ramp up
Time.
t s x n Hz
dec s
Par . 3 − 62 =
ref Hz
Function:
Select the ramp type, depending on
requirements for acceleration/deceleration. A
linear ramp gives constant acceleration during
ramping. An S-ramp gives non-linear
acceleration.
Danfoss A/S © 06/2017 All rights reserved.
®
AutomationDrive FC 360
3-70 Ramp 4 Type
Option:
[2] Sine 2
Ramp
3-71 Ramp 4 Ramp up Time
Range:
Size
related
*
3-72 Ramp 4 Ramp Down Time
Range:
Size
related 3600 s]
*
4.4.7 3-8* Other Ramps
3-80 Jog Ramp Time
Range:
Size
related - 3600
*
s]
Function:
S-ramp based on the values set in
parameter 3-71 Ramp 4 Ramp up Time and
parameter 3-72 Ramp 4 Ramp Down Time.
Function:
[0.01 - Enter the ramp-up time, which is the
3600 s] acceleration time from 0 Hz to the rated
motor speed n . Select a ramp-up time
s
such that the output current does not
exceed the current limit in
parameter 4-18 Current Limit during
ramping. See ramp-down time in
parameter 3-72 Ramp 4 Ramp Down Time.
t s x n Hz
acc s
Par . 3 − 71 =
ref Hz
Function:
[0.01 - Enter the ramp-down time, which is the
deceleration time from the rated motor
speed n to 0 Hz. Select a ramp-down time
s
such that no overvoltage arises in the
inverter due to regenerative operation of the
motor, and such that the generated current
does not exceed the current limit set in
parameter 4-18 Current Limit. See ramp-up
time in parameter 3-71 Ramp 4 Ramp up
Time.
t s x n Hz
dec s
Par . 3 − 72 =
ref Hz
Function:
[0.01 Enter the jog ramp time, which is the
acceleration/deceleration time between 0 Hz
and the rated motor frequency n
the resulting output current required for the
given jog ramp time does not exceed the
current limit in parameter 4-18 Current Limit.
The jog ramp time starts when activating a
jog signal via the LCP, a selected digital
output, or the serial communication port.
When jog state is disabled, the normal
ramping times are valid.
. Ensure that
s
