Parameter Descriptions
8-19 Product Code
Range:
Size
[0 -
related
2147483647]
*
4
4
4.9.3 8-3* FC Port Settings
8-30 Protocol
Option:
[0]
FC
*
[2]
Modbus RTU Communication according to the Modbus
8-31 Address
Range:
1
[ 0 - 247 ] Enter the address for the RS485 port. Valid range:
*
8-32 Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-33 Parity / Stop Bits
Option:
[0]
Even Parity, 1 Stop Bit
*
[1]
Odd Parity, 1 Stop Bit
[2]
No Parity, 1 Stop Bit
[3]
No Parity, 2 Stop Bits
8-35 Minimum Response Delay
Range:
0.01 s
[ 0.0010 - 0.5
*
s]
80
VLT
Function:
Select 0 to read out the actual
fieldbus product code according
to the mounted fieldbus option.
Select 1 to read out the actual
vendor ID.
Function:
Select the protocol for the integrated RS485
port.
Communication according to the FC protocol.
RTU protocol.
Function:
1–126 for FC-bus, or 1–247 for Modbus.
Function:
Select the baud rate for the RS485 port.
Function:
Function:
Specify the minimum delay time
between receiving a request and
transmitting a response. This is used for
overcoming modem turn-around
delays.
Danfoss A/S © 06/2017 All rights reserved.
®
AutomationDrive FC 360
8-36 Maximum Response Delay
Range:
Size related
*
4.9.4 8-4* FC MC Protocol Set
8-42 PCD Write Configuration
Select the parameters to be assigned to the PCD's telegrams. The
number of available PCDs depends on the telegram type. The
values in the PCDs are then written to the selected parameters as
data values.
Enter up to 16 different preset mapping 0–15 in this parameter,
using array programming. If this parameter is active, addresses
2810–2825 represent values of the 16 parameters. If this
parameter is not active, addresses 2810 and 2811 are used as
input-data-drive control word and bus reference. Addresses
2812–2825 are reserved.
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[15]
[16]
[18]
Function:
[ 0.1 - 10.0
Specify the maximum allowed delay
s]
time between receiving a request and
transmitting the response. If this time
is exceeded, no response is returned.
None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp up
time
[342] Ramp 1 Ramp down
time
[351] Ramp 2 Ramp up
time
[352] Ramp 2 Ramp down
time
[380] Jog Ramp Time
[381] Quick Stop Time
[412] Motor Speed Low
Limit [Hz]
[414] Motor Speed High
Limit [Hz]
[590] Digital & Relay Bus
Control
[676] Terminal45 Output
Bus Control
[696] Terminal 42 Output
Bus Control
FC Port CTW
FC Port REF
[311] Jog Speed [Hz]
Function:
MG06C702
