Parameter Descriptions
1-49 Current at Min Inductance for q-axis
Range:
100 %
[ 20 -
200 %]
4
4
4.2.6 1-5* Load Indep. Setting
Parameters for load-independent motor settings.
1-50 Motor Magnetisation at Zero Speed
Range:
100
[0 -
%
300 %
*
]
1-52 Min Speed Normal Magnetising [Hz]
Range:
1 Hz
[ 0.1 - 10.0
*
Hz]
1-55 U/f Characteristic - U
Range:
Size
related
V]
*
40
Function:
This parameter specifies the saturation curve of
the q-inductance values. From 20–100% of this
parameter, the inductance is linearly
approximated due to parameter 1-38 q-axis
Inductance (Lq) and parameter 1-45 q-axis
Inductance Sat. (LqSat). These parameters are
related to the motor nameplate load compen-
sations, the application load type, and the
electronic brake function for quick stop/hold of
the motor.
Function:
Use this parameter along with parameter 1-52 Min
Speed Normal Magnetising [Hz] to obtain a
different thermal load on the motor when running
at low speed.
Enter a value that is a percentage of the rated
magnetizing current. If the setting is too low, the
torque on the motor shaft may be reduced.
Magn. current
90%
Par.1-50
Par.1-52
Illustration 4.2 Motor Magnetization
Function:
Set the required frequency for normal
magnetizing current. Use this parameter
along with parameter 1-50 Motor Magneti-
sation at Zero Speed, also see Illustration 4.2.
Function:
[0 - 1000
Enter voltage at each frequency point
to manually form a U/f characteristic
matching motor. Frequency points are
defined in parameter 1-56 U/f Charac-
teristic - F.
Danfoss A/S © 06/2017 All rights reserved.
®
VLT
AutomationDrive FC 360
1-56 U/f Characteristic - F
Range:
Size
related
*
4.2.7 1-6* Load Depen. Setting
Parameters for adjusting the load-dependent motor
settings.
1-60 Low Speed Load Compensation
Range:
100 %
*
Hz
1-61 High Speed Load Compensation
Range:
100 %
*
1-62 Slip Compensation
Range:
Size
related
*
Function:
[ 0 -
Enter frequency points to form a U/f charac-
500.0
teristic matching motor. Voltage at each point
Hz]
is defined in parameter 1-55 U/f Characteristic
- U.
Make a U/f characteristic based on 6
definable voltages and frequencies, see
Illustration 4.3.
Motor Voltage
Par 1-55 [x]
1-55[5]
1-55[4]
1-55[3]
1-55[2]
1-55[1]
1-55[0]
1-56
1-56
1-56
[0]
[1]
[2]
Illustration 4.3 Example of U/f Charac-
teristic
Function:
[0 -
Enter the low-speed voltage compensation
300 %]
value in percent. This parameter is used for
optimizing the low-speed load performance.
This parameter is only active if
parameter 1-10 Motor Construction = [0]
Asynchron.
Function:
[0 -
Enter the high-speed load voltage compen-
300 %]
sation value in percent. This parameter is
used for optimizing the high-speed load
performance. This parameter is only active if
parameter 1-10 Motor Construction = [0]
Asynchron.
Function:
[ -400 -
Enter the % value for slip compensation
400.0 %]
to compensate for tolerance in the
value of n
. Slip compensation is
M,N
calculated automatically, that is, based
on the nominal motor speed n
1-56
1-56
1-56
[5]
[3]
[4]
Output Frequency
Par 1-56 [x]
.
M,N
MG06C702
