Danfoss VLT AutomationDrive FC 360 Programming Manual page 84

Parameter Descriptions
8-52 DC Brake Select
Option:
4 4
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR Activate DC brake command via the fieldbus/
*
8-53 Start Select
Select the trigger for the start function.
Option:
[0] Digital input A digital input triggers the start function.
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-55 Set-up Select
Select the trigger for the set-up selection.
Option:
[0] Digital input A digital input triggers the set-up selection.
[1] Bus
82
VLT
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, only
selection [0] Digital input is available.
Activate DC brake command via a digital input.
Activate DC brake command via the serial
communication port or fieldbus option.
Activate DC brake command via the fieldbus/
serial communication port and additionally via 1
of the digital inputs.
serial communication port or via 1 of the digital
inputs.
Function:
A serial communication port or the fieldbus
triggers the start function.
The fieldbus/serial communication port and a
digital input trigger the start function.
The fieldbus/serial communication port or a
digital input triggers the start function.
Function:
Select the trigger for the reversing function.
A digital input triggers the reversing function.
A serial communication port or the fieldbus
triggers the reversing function.
The fieldbus/serial communication port and a
digital input trigger the reversing function.
The fieldbus/serial communication port or a
digital input triggers the reversing function.
Function:
A serial communication port or the fieldbus
triggers the set-up selection.
Danfoss A/S © 06/2017 All rights reserved.
®
AutomationDrive FC 360
8-55 Set-up Select
Select the trigger for the set-up selection.
Option:
[2] Logic AND
[3] Logic OR
*
8-56 Preset Reference Select
Option:
[0] Digital
input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-57 Profidrive OFF2 Select
Select control of the frequency converter OFF2 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when parameter 8-01 Control Site is set to [0] Digital
and ctrl. word and parameter 8-10 Control Word Profile is set to [1]
Profidrive profile.
Option:
[0]
[1]
[2]
[3]
*
8-58 Profidrive OFF3 Select
Select control of the frequency converter OFF3 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when parameter 8-01 Control Site is set to [0] Digital
and ctrl. word, and parameter 8-10 Control Word Profile is set to [1]
Profidrive profile.
Option:
[0]
[1]
[2]
[3]
*
Function:
The fieldbus/serial communication port and a
digital input trigger the set-up selection.
The fieldbus/serial communication port or a
digital input triggers the set-up selection.
Function:
Select the trigger for the preset reference
selection.
A digital input triggers the preset reference
selection.
A serial communication port or the fieldbus
triggers the preset reference selection.
The fieldbus/serial communication port and a
digital input trigger the preset reference
selection.
The fieldbus/serial communication port or a
digital input triggers the preset reference
selection.
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
Digital input
Bus
Logic AND
Logic OR
MG06C702
