Wacker Neuson Telehandler TH412 Operator's Manual page 93

Table of Contents

Advertisement

Item Designation
Indicating instrument
1
Parking brake control lever
2
3
Stability display
Mast control lever
4
Rocker switch panel 4
5
6
Control lever for auxiliary hydraulics
Starter
7
Fuse box
8
Accelerator pedal
9
Operator seat
10
BA TH412 * 06/2017 * 4512_4-2_Bedienelemente_en.fm
Item Designation
Brake/inching pedal
11
Rotary knob for manual inching (option)
12
13
Rocker switch panel 3
Power outlet
14
Rocker switch panel 1
15
Steering-column control lever (option)
16
Steering wheel
17
Rocker switch panel 2
18
Putting into operation 4
4-19
