9 Technical data
9.13 Weights
Vehicle weight
Weight indications
Operating weight
Permissible maximum weight
Payload/axle load/bearing load
Payload and axle load
Weight indications
Permissible axle loads per axle
Permissible payload with pallet fork 1000227130 according to EN 1459 Annex B, telescopic
boom retracted
Permissible payload with pallet fork 1000227130 according to EN 1459 Annex B, telescopic
boom extended
Permissible trailer loads with a braked trailer and a maximum incline of 10 %
Permissible trailer loads with an unbraked trailer and a maximum incline of 10%
Permissible drawbar load on trailer coupling
9-12
Diesel engine 22.6KW
2530 kg (5578 lbs)
3100 kg (6834 lbs)
BA TH412 * 06/2017 * 4512_9_Tech_Daten_en.fm
Diesel engine 29.9 kW
2572 kg (5670 lbs)
3100 kg (6834 lbs)
2000 kg (4409 lbs)
1200 kg (2645 lbs)
440 kg (970 lbs)
4000 kg (8818 lbs)
750 kg (1653 lbs)
75 kg (165 lbs)
