4 Putting into operation
Rocker switch for "High Flow" hydraulic connec-
tions (optional)
49
The rocker switch 49 is located in Rocker switch panel 4.
The hydraulic "High-Flow" connections on the mast can
be operated with this function. This function is required for
constant-operation attachments requiring a higher oil flow
rate. If the machine is equipped with the "High Flow"
system then the "Detent mechanism for the control lever
for the additional hydraulics" is fitted as standard.
Operating "High Flow" hydraulic connections on
page 5-91
4-36
Rocker switch "Three-point receptacle at the rear"
(optional)
50
Switch 50 is located on the right beside the operator seat,
behind the control lever for the auxiliary hydraulics. The 3-
point mount can be raised and lowered with the switch.
Operating the rear 3-point mount on page 5-95
BA TH412 * 06/2017 * 4512_4-3_Warnleuchten_en.fm
