5 Operation
Safe load indicator
85%
40%
3
Fig. 82
CAUTION
Accident hazard due to tipping over of machine!
The safe load indicator only gives a warning in the event
of insufficient stability in the longitudinal direction and
toward the front. Lateral loads are not indicated by the
safe load indicator.
5-56
Always pay attention to the stability display 3 at the upper
right in the cabin while working. The display of the safe
load indicator indicates machine stability as a function of
the raised load. The safe load indicator gives visual and
acoustic signals.
1. Green up to 40%: There is no risk of the machine
tipping over, all travel and work movements can be
continued.
Green up to 85%: There is a slight risk of the machine
tipping over, pay attention to the display of the safe
load indicator for further travel and work movements.
2. Orange: There is an increased risk of the machine
tipping over. Perform further travel and work
movements with caution.
3. Red: There is an imminent risk of the machine tipping
over!
- With an extended boom: the overload protection is
active.
- With the telescopic boom retracted: Immediately
stop the work movement currently being carried out.
Retract the telescopic boom or lower the loader unit.
BA TH412 * 06/2017 * 4512_5-11_Arbeitsbetrieb_en.fm
